60 Hydraulic Roof Support Units Supplied for Indonesia Underground Mine
Hydraulic Roof Supports Supplied for an Underground Mining Project in Indonesia
On June 25, 2026, TAIDA GLOBAL coordinated the supply of 60 hydraulic roof supports for an underground mining project in East Kalimantan, Indonesia.
The equipment was configured for underground working-face support and equipped with an electro hydraulic control system to support coordinated operation and operating-status management.
Main Equipment Data
Equipment type: Four-leg shield hydraulic roof support
Model: ZZ9400/26/55D
Project quantity: 60 units
Rated working resistance: 9,400 kN
Support height range: 2,600-5,500 mm
Applicable working-face inclination: ≤10°
Control system: Electro-hydraulic control
Application: Underground mine working-face support
Before shipment preparation, the completed supports were arranged in the workshop for inspection. The inspection scope included the main load-bearing structure, hydraulic cylinders, pin connections, hydraulic hoses, fittings, equipment identification, assembly completeness, and visible surface condition.
The hydraulic system was also checked for correct component installation, hose routing, connection reliability, and visible leakage. Functional movements and control-related items were reviewed according to the approved project requirements and inspection procedure.
Because the hydraulic roof supports are large and heavy mining equipment, the loading and transportation plan needed to consider unit dimensions, gross weight, center of gravity, lifting points, support positions, securing methods, vehicle arrangement, transport route, and destination unloading conditions.
TAIDA GLOBAL coordinated technical requirement clarification, supplier communication, quality inspection, export packing, loading preparation, transport documentation, and delivery planning for the project.
