ZY3800 16 32 Shield Roof Support

01 | KEY TECHNICAL ATTRIBUTES

1. Product: ZY3800 16 32 Shield Roof Support

2. Sourcing brand: TAIDA GLOBAL (procurement coordination platform; not a claim to be the equipment manufacturer or an authorized brand agent).

3. Category: Hydraulic Roof Supports

4. Typical application: continuously advancing medium-thick coal seam face.

5. Support height: 1.6–3.2 m.

6. Rated working resistance: 3800 kN.

7. Functional configuration: two-leg shield configuration.

8. Critical technical interfaces and compatibility: canopy and shield alignment, hydraulic leg capacity, floor bearing pressure and shearer/AFC interfaces.

9. Factory inspection / FAT / SAT focus: hydrostatic pressure testing, functional movement, structural welds and interlocks.

10. Site safety: Confirm strata conditions and integrated longwall equipment compatibility; obtain mine-specific approvals.

11. Utilities and controls: confirm actual operating voltage/frequency, hydraulic fluid, connectors and protocols; do not assume 380 V/50 Hz.

12. Request a current manufacturer datasheet, drawings, material and test records, relevant certificates and agreed FAT/SAT checklist.

13. Specification status: Values are drawn from third-party model references; the cited source is not proof that TAIDA GLOBAL sells, stocks or represents this model.

14. Manufacturer and country of origin: not verified; do not infer them from the third-party reference site.

02 | REGIONAL SHIPMENT & DELIVERY GUIDANCE

1. Production lead time: unconfirmed until a manufacturer supplies a written production schedule; include design, material procurement, fabrication, tests, inspection and packing.

2. Shipment: ZY3800 16 32 Shield Roof Support. Confirm actual packed dimensions, per-piece gross weight, split modules, handling, hydraulic fluid, battery and hazardous-goods rules.

3. Historic ordinary sea-freight ETD-to-ETA reference ONLY (from an older crane template; NOT verified 2026 sailings or equipment-specific quotes):

  • Southeast Asia: Shanghai → Surabaya, Indonesia; indicative 12–20 days.

  • East Asia: Shanghai → Incheon, South Korea; indicative 3–8 days.

  • Middle East: Shanghai → Khalifa Port, UAE; indicative 18–28 days.

  • Africa: Shanghai → Tangier, Morocco; indicative 32–50 days.

  • Europe: Shanghai → Hamburg, Germany; indicative 36–53 days.

  • Americas: Shanghai → Vancouver, Canada; indicative 15–26 days.

4. These ranges must NOT be used for contractual delivery commitments or special/out-of-gauge cargo without fresh carrier quotations.

5. Inland transport in China, customs, export handling, loading, booking queues and origin-port time are excluded.

6. Breakbulk, open-top/flat-rack, oversized machinery, batteries and explosion-protected electronics may require different handling and transit.

7. Port discharge, import clearance, taxes, last-mile delivery, mine entry, installation, commissioning and SAT are excluded. Confirm Incoterms, route and schedule in writing.

03 | CUSTOM OPTIONS & PROCUREMENT HIGHLIGHTS

1. Define the application: continuously advancing medium-thick coal seam face. Confirm site operating loads, interfaces and local requirements before requesting a configuration.

2. Primary selection criterion: Support height: 1.6–3.2 m; verify engineering calculations and applicable test conditions.

3. Secondary selection criterion: Rated working resistance: 3800 kN; match component capacities, materials and safety margins.

4. Core functional focus: two-leg shield configuration; identify which parts are standard versus optional/custom supply.

5. Interface and replacement requirements: canopy and shield alignment, hydraulic leg capacity, floor bearing pressure and shearer/AFC interfaces. For a replacement part, supply OEM model, part number, drawings, mounting dimensions and site photos.

6. Pre-quote technical comparison should explicitly address hydrostatic pressure testing, functional movement, structural welds and interlocks; document deviations to avoid rework and mismatched interfaces.

7. Optional scope (subject to quotation): equipment/components, connection pieces, inspection records, spare parts, commissioning assistance and operator training.

8. Evaluate total cost of procurement: equipment, spares, consumables, inspection/compliance, packing, insurance, freight, installation, energy use and downtime. No unverified cost-saving percentage is claimed.

9. Engineering safeguard: Confirm strata conditions and integrated longwall equipment compatibility; obtain mine-specific approvals.
